| Installation position | Internal |
| Operating voltage | 24VDC |
| Maximum pressure | 4.5MPa |
| Reservoir | 2L |
| Applicable media | L-HS 46# hydraulic oil |
| Display mode | LCD dynamic display: counting, rest time, grease discharge time, grease suction time, temperature,fuid level, fault code, etc. |
| Grease discharge time | (1-99)min, adjustable |
| Grease suction time | (1-99)min, adjustable |
| Rest time | (1-30)h adjustable |
| Operating temperature | -40°C~70°C |
