| Maximum operating pressure | 35MPa |
| Minimum operating pressure | 2MPa |
| Number of outlets | 6-22 |
| Inlet thread | M10* 1 |
| Outlet thread | M10* 1 |
| Connectable lubrication line |
Ø 6 |
| Metering volume per stroke and outlet | The metering volume is adjusted via metering screws and amounts to a maximum of 1.8 cm3 per stroke |
| Material version | Steel, |
| Function monitoring | Proximity switch |
| Ambient temperature range | -40℃--80℃ |
| Suitable lubrication grease consistencies | Lubrication greases up to and including NLGI 2 |
| Suitable lubrication oil viscosities | Lubrication oils of at least 40 mm2/s at ambient temperature |
