| Model | ALPB130 series |
| Function principle | Electric plunger pump |
| Operating temperature | -40℃~70℃ |
| Oil tank capacity | 20 L & 30 L |
| Voltage | DC12V/DC24V/AC230V |
| Operating current | ≤3A |
| Number of outlets | 1-4 |
| Oil output | 1.5 ml/min, 2.5 ml/min & 4.5 ml/min, |
| Operating pressure | 30MPa |
| Applicable grease | NLGI-0#, 1# & 2# |
| IP grade | IP66 |
| Monitor | External/internal layout |
| Mounting position | any |
